CQ is Allen & Heath’s most compact digital mixer range ever.
Built on a 96kHz processing engine, it’s rich in connectivity with Bluetooth, wireless
options, SD and USB audio recording and playback.
Focusing on speed and ease of use - brand new Quick Channels, Gain/Feedback
Assistants and signal conscious FX enhance the world-renowned audio and build
quality that users expect from Allen & Heath.
Offered in three form factors – two desktop models with hands-on control and one
stage box model. All utilise the same technology, apps, and UI but with slightly
different feature sets and price points.
With the CQ range, Allen & Heath have created a super portable and fun to use, but
still fully featured digital mixer, suitable for technical and non-technical users alike.
CQ is designed to be used anywhere high-quality sound processing and summing is
required, from bands and producers to AV and rental, from the main mixer in a small
venue to a sub mixer on the largest stage.
•16 Mic/Line preamps, 8x XLR + 8x XLR/TRS ‘Combi’
•Balanced stereo line input, 2x TRS
•Main LR, 2x XLR
•6x Monitor Mixes, 6x TRS
•2x Assignable headphone outputs, 2x 6.35mm TRS
•24x22 USB-B interface
•24x22 SD record/playback
•Stereo USB record/playback with dedicated input channel
•Stereo Bluetooth playback with dedicated input channel
•4x FX Assist engines
•3x Custom SoftKeys
•3x Smart Rotaries
•Dual Footswitch connection
•7” Capacitive touchscreen with associated rotary control
•Built-in dual band 2.4G/5G AC Wi-Fi with auto channel select
•346mm x 242mm x 88mm, 3kg
